Table 23: Multi-pump monitoring
Index Monitoring value Unit Scale ID Description
V2.10.1 Motors Running 1 30
V2.10.2 Autochange 1 1114
V2.10.3 Next Autochange h 0.1 1503
V2.10.4 Operate Mode 1 1505
0 = Slave
1 = Master
V2.10.5 Multi-pump Status 1 1628
0 = Not used
10 = Stopped
20 = Sleep
30 = Anti-blocking
40 = Auto-cleaning
50 = Flushing
60 = Soft filling
70 = Regulating
80 = Following
90 = Const. producing
200 = Unknown
V2.10.6
Communication
Status
h 0.1 1629
0 = Not used (Multi-pump multidrive function)
10 = Fatal communication errors occurred
(or no communication)
11 = Errors occurred (data sending)
12 = Errors occurred (data receiving)
20 = Communication operational, no errors
occurred
30 = Status unknown
V2.10.7
Pump (1) Running
Time
h 0.1 1620
V2.10.8
Pump 2 Running
Time
h 0.1 1621
V2.10.9
Pump 3 Running
Time
h 0.1 1622
V2.10.10
Pump 4 Running
Time
h 0.1 1623
V2.10.11
Pump 5 Running
Time
h 0.1 1624
V2.10.12
Pump 6 Running
Time
h 0.1 1625
V2.10.13
Pump 7 Running
Time
h 0.1 1626
V2.10.14
Pump 8 Running
Time
h 0.1 1627
