Vacon 100 flow Applications Manual

5.3 GROUP 3.3: REFERENCES
Table 34: Frequency reference parameters
Index Parameter Min Max Unit Default ID Description
P3.3.1.1
Minimum Frequency
Reference
0.00 P3.3.1.2 Hz 0.00 101
P3.3.1.2
Maximum Frequency
Reference
P3.3.1.1 320.00 Hz
50.00 /
60.00
102
P3.3.1.3
Positive Frequency
Reference Limit
-320.0 320.0 Hz 320.00 1285
P3.3.1.4
Negative Frequency
Reference Limit
-320.0 320.0 Hz -320.00 1286
P3.3.1.5
I/O Control Refer-
ence A Selection
0 20 6 * 117
0 = PC
1 = Preset frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID
8 = Motor potentiome-
ter
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
P3.3.1.6
I/O Control Refer-
ence B Selection
0 20 4 * 131
PARAMETERS MENU VACON · 133
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
