Table 34: Frequency reference parameters
Index Parameter Min Max Unit Default ID Description
P3.3.1.7
Keypad Control Ref-
erence Selection
0 20 1 * 121
0 = PC
1 = Preset frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID
8 = Motor potentiome-
ter
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
P3.3.1.8
Keypad Reference 0.00 P3.3.1.2. Hz 0.00 184
P3.3.1.9 Keypad Direction 0 1 0 123
0 = Forward
1 = Reverse
P3.3.1.10
Fieldbus Control
Reference Selection
0 20 2 * 122
0 = PC
1 = Preset frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID
8 = Motor potentiome-
ter
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in Chapter 12.1 The default values of parameters in the different
applications.
