Table 35: Preset frequency parameters
Index Parameter Min Max Unit Default ID Description
P3.3.3.1
Preset Frequency
Mode
0 1 0 * 182
0 = Binary coded
1 = Number of inputs
P3.3.3.2 Preset Frequency 0 P3.3.1.1 P3.3.1.2 Hz 5.00 180
P3.3.3.3 Preset Frequency 1 P3.3.1.1 P3.3.1.2 Hz 10.00 * 105
P3.3.3.4 Preset Frequency 2 P3.3.1.1 P3.3.1.2 Hz 15.00 * 106
P3.3.3.5 Preset Frequency 3 P3.3.1.1 P3.3.1.2 Hz 20.00 * 126
P3.3.3.6 Preset Frequency 4 P3.3.1.1 P3.3.1.2 Hz 25.00 * 127
P3.3.3.7 Preset Frequency 5 P3.3.1.1 P3.3.1.2 Hz 30.00 * 128
P3.3.3.8 Preset Frequency 6 P3.3.1.1 P3.3.1.2 Hz 40.00 * 129
P3.3.3.9 Preset Frequency 7 P3.3.1.1 P3.3.1.2 Hz 50.00 * 130
P3.3.3.10
Preset Frequency
Selection 0
DigIN
SlotA.4
419
P3.3.3.11
Preset Frequency
Selection 1
DigIN
SlotA.5
420
P3.3.3.12
Preset Frequency
Selection 2
DigIN
Slot0.1
421
* The default value of the parameter is specified by the application that you select with
parameter P1.2 Application. See the default values in Chapter 12.1 The default values of
parameters in the different applications.
Table 36: Motor potentiometer parameters
Index Parameter Min Max Unit Default ID Description
P3.3.4.1
Motor Potentiometer
UP
DigIN
Slot0.1
418
OPEN = Not active
CLOSED = Active
P3.3.4.2
Motor Potentiometer
DOWN
DigIN
Slot0.1
417
OPEN = Not active
CLOSED = Active
P3.3.4.3
Motor Potentiometer
Ramp Time
0.1 500.0 Hz/s 10.0 331
P3.3.4.4
Motor Potentiometer
Reset
0 2 1 367
0 = No reset
1 = Reset if stopped
2 = Reset if powered
down
PARAMETERS MENU VACON · 135
