Vacon 100 flow Applications Manual

5.17 GROUP 3.17: FIRE MODE
Table 95: Fire mode parameters
Index Parameter Min Max Unit Default ID Description
P3.17.1 Fire Mode Password 0 9999 0 1599
1002 = Enabled
1234 = Test mode
P3.17.2
Fire Mode Frequency
Source
0 18 0 1617
0 = Fire Mode fre-
quency
1 = Preset speeds
2 = Keypad
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1 + AI2
7 = PID1
8 = Motor potentiome-
ter
9 = Block Out.1
10 = Block Out.2
11 = Block Out.3
12 = Block Out.4
13 = Block Out.5
14 = Block Out.6
15 = Block Out.7
16 = Block Out.8
17 = Block Out.9
18 = Block Out.10
P3.17.3
Fire Mode Frequency 0.00 P3.3.1.2 Hz 50.00 1598
P3.17.4
Fire Mode Activation
on OPEN
DigIN
Slot0.2
1596
OPEN = Fire Mode
active
CLOSED = No action
P3.17.5
Fire Mode Activation
on CLOSE
DigIN
Slot0.1
1619
OPEN = No action
CLOSED = Fire Mode
active
P3.17.6 Fire Mode Reverse
DigIN
Slot0.1
1618
OPEN = Forward
CLOSED = Reverse
DigIN Slot0.1 = For-
ward
DigIN Slot0.2 = Reverse
V3.17.7 Fire Mode Status 0 3 1597
See Table 16 Items in
the monitoring menu.
0 = Disabled
1 = Enabled
2 = Activated (Enabled
+ DI Open)
3 = Test Mode
V3.17.8 Fire Mode Counter 0 65535 1679
PARAMETERS MENU VACON · 181
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
