Vacon 100 flow Applications Manual

5.13 GROUP 3.13: PID CONTROLLER
Table 74: PID controller 1 basic settings
Index Parameter Min Max Unit Default ID Description
P3.13.1.1 PID Gain 0.00 1000.00 % 100.00 118
P3.13.1.2 PID Integration Time 0.00 600.00 s 1.00 119
P3.13.1.3 PID Derivation Time 0.00 100.00 s 0.00 132
P3.13.1.4
Process Unit Selec-
tion
1 46 1 1036
1 = %
2 = 1/min
3 = rpm
4 = ppm
5 = pps
6 = l/s
7 = l/min
8 = l/h
9 = kg/s
10 = kg/min
11 = kg/h
12 = m
3
/s
13 = m
3
/min
14 = m
3
/h
15 = m/s
16 = mbar
17= bar
18 = Pa
19 = kPa
20 = mVS
21 = kW
22 = °C
23 = gal/s
24 = gal/min
25 = gal/h
26 = lb/s
27 = lb/min
28 = lb/h
29 = ft
3
/s
30 = ft
3
/min
31 = ft
3
/h
32 = ft/s
33 = in wg
34 = ft wg
35 = SPI
36 = lb/in
2
37 = psig
38 = hp
39 = °F
40 = ft
41 = inch
42 = mm
43 = cm
44 = m
45 = gpm
46 = cfm
VACON · 162 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
