Table 74: PID controller 1 basic settings
Index Parameter Min Max Unit Default ID Description
P3.13.1.5 Process Unit Min Varies Varies Varies 0 1033
P3.13.1.6 Process Unit Max Varies Varies Varies 100 1034
P3.13.1.7
Process Unit Deci-
mals
0 4 2 1035
P3.13.1.8 Error Inversion 0 1 0 340
0 = Normal (Feedback
< Setpoint -> Increase
PID output)
1 = Inverted (Feedback
< Setpoint -> Decrease
PID output )
P3.13.1.9 Dead Band 0.00
99999.9
9
Varies 0 1056
P3.13.1.10 Dead Band Delay 0.00 320.00 s 0.00 1057
PARAMETERS MENU VACON · 163
