Vacon 100 flow Applications Manual

Table 37: Flushing parameters
Index Parameter Min Max Unit Default ID Description
P3.3.6.1
Flushing Reference
Activation
DigIN
Slot0.1 *
530
P3.3.6.2 Flushing reference -MaxRef MaxRef Hz 0.00 * 1239
* The default value of the parameter is specified by the application that you select with
parameter P1.2 Application. See the default values in Chapter 12.1 The default values of
parameters in the different applications.
5.4 GROUP 3.4: RAMPS AND BRAKES SETUP
Table 38: Ramp 1 setup
Index Parameter Min Max Unit Default ID Description
P3.4.1.1 Ramp 1 Shape 0.0 100.0 % 0.0 500
P3.4.1.2 Acceleration Time 1 0.1 3000.0 s 5.0 103
P3.4.1.3 Deceleration Time 1 0.1 3000.0 s 5.0 104
Table 39: Ramp 2 setup
Index Parameter Min Max Unit Default ID Description
P3.4.2.1 Ramp 2 Shape 0.0 100.0 % 0.0 501
P3.4.2.2 Acceleration Time 2 0.1 3000.0 s 10.0 502
P3.4.2.3 Deceleration Time 2 0.1 3000.0 s 10.0 503
P3.4.2.4 Ramp 2 Selection Varies Varies
DigIN
Slot0.1
408
OPEN = Ramp 1 Shape,
Acceleration Time 1
and Deceleration Time
1.
CLOSED = Ramp 2
Shape, Acceleration
Time 2 and Decelera-
tion Time 2.
P3.4.2.5
Ramp 2 Threshold
Frequency
0.0 P3.3.1.2 Hz 0.0 533
0 = Not used
VACON · 136 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
