10.6.2 DEFAULT FUNCTIONS OF PROGRAMMABLE INPUTS
Table 120: Default functions of the programmable digital and analogue inputs
Input Terminal(s) Reference Function Parameter index
DI1 8 A.1 Control Signal 1 A P3.5.1.1
DI2 9 A.2 Control Signal 2 A P3.5.1.2
DI3 10 A.3 External Fault Close P3.5.1.11
DI4 14 A.4
Preset Frequency
Selection 0
P3.5.1.21
DI5 15 A.5
Preset Frequency
Selection 1
P3.5.1.22
DI6 16 A.6 Fault Reset Close P3.5.1.13
AI1 2/3 A.1 AI1 Signal Selection P3.5.2.1.1
AI2 4/5 A.2 AI2 Signal Selection P3.5.2.2.1
10.6.3 DIGITAL INPUTS
The parameters are functions that you can connect to a digital input terminal. The text DigIn
Slot A.2 means the second input on the slot A. It is also possible to connect the functions to
time channels. The time channels work as terminals.
You can monitor the statuses of the digital inputs and the digital outputs in the
Multimonitoring view.
P3.5.1.1 CONTROL SIGNAL 1 A (ID 403)
Use this parameter to select the digital input signal (Control Signal 1) that starts and stops
the drive when the control place is I/O A (FWD).
P3.5.1.2 CONTROL SIGNAL 2 A (ID 404)
Use this parameter to select the digital input signal (Control Signal 2) that starts and stops
the drive when the control place is I/O A (REV).
P3.5.1.3 CONTROL SIGNAL 3 A (ID 434)
Use this parameter to select the digital input signal (Control Signal 3) that starts and stops
the drive when the control place is I/O A.
P3.5.1.4 CONTROL SIGNAL 1 B (ID 423)
Use this parameter to select the digital input signal (Control Signal 1) that starts and stops
the drive when the control place is I/O B.
PARAMETER DESCRIPTIONS VACON · 261
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
