Vacon 100 flow Applications Manual

Table 20: Monitoring of the timer functions
Index Monitoring value Unit Scale ID Description
V2.7.1 TC 1, TC 2, TC 3 1 1441
V2.7.2 Interval 1 1 1442
V2.7.3 Interval 2 1 1443
V2.7.4 Interval 3 1 1444
V2.7.5 Interval 4 1 1445
V2.7.6 Interval 5 1 1446
V2.7.7 Timer 1 s 1 1447
V2.7.8 Timer 2 s 1 1448
V2.7.9 Timer 3 s 1 1449
V2.7.10 Real time clock 1450
4.1.8 PID CONTROLLER MONITORING
Table 21: Monitoring of the values of the PID controller
Index Monitoring value Unit Scale ID Description
V2.8.1 PID Setpoint Varies
As is set
in
P3.13.1.7
20
V2.8.2 PID Feedback Varies
As is set
in
P3.13.1.7
21
V2.8.3 PID Feedback (1) Varies
As is set
in
P3.13.1.7
15541
V2.8.4 PID Feedback (2) Varies
As is set
in
P3.13.1.7
15542
V2.8.5 PID Error Varies
As is set
in
P3.13.1.7
22
V2.8.6 PID Output % 0.01 23
V2.8.7 PID Status 1 24
0 = Stopped
1 = Running
3 = Sleep mode
4 = In dead band (see 5.13 Group 3.13: PID
controller)
VACON · 122 MONITORING MENU
4
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
