Page #137 background imageLoading...
Page #137 background image
Table 40: Start magnetisation parameters
Index Parameter Min Max Unit Default ID Description
P3.4.3.1
Start Magnetising
Current
0.00 IL A IH 517
0 = Disabled
P3.4.3.2
Start Magnetising
Time
0.00 600.00 s 0.00 516
Table 41: DC brake parameters
Index Parameter Min Max Unit Default ID Description
P3.4.4.1 DC Brake Current 0 IL A IH 507 0 = Disabled
P3.4.4.2
DC Braking Time at
Stop
0.00 600.00 s 0.00 508
0 = DC braking not
used
P3.4.4.3
Frequency to Start
DC Braking at Ramp
Stop
0.10 10.00 Hz 1.50 515
Table 42: Flux braking parameters
Index Parameter Min Max Unit Default ID Description
P3.4.5.1 Flux Braking 0 1 0 520
0 = Disabled
1 = Enabled
P3.4.5.2 Flux Braking Current 0 IL A IH 519
PARAMETERS MENU VACON · 137
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5
