Vacon 100 flow Applications Manual

Table 89: Multi-pump parameters
Index Parameter Min Max Unit Default ID Description
P3.15.16
Running Pumps
Limit
1 P3.15.2 3 * 1187
M3.15.17 Interlock Signals See the interlock signal parameters below.
M3.15.18
Overpressure Super-
vision
See the overpressure supervision parameters below.
M3.15.19 Pump Running Time See the pump running time counter parameters below.
M3.15.22 Advanced Settings See the parameters for advanced settings below.
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in 12.1 The default values of parameters in the different applications.
Table 90: Interlock signals
Index Parameter Min Max Unit Default ID Description
P3.15.17.1 Pump 1 interlock Varies Varies
DigIN
Slot0.1
426
OPEN = Not active
CLOSED = Active
P3.15.17.2 Pump 2 interlock Varies Varies
DigIN
Slot0.1
427
OPEN = Not active
CLOSED = Active
P3.15.17.3 Pump 3 interlock Varies Varies
DigIN
Slot0.1
428
OPEN = Not active
CLOSED = Active
P3.15.17.4 Pump 4 interlock Varies Varies
DigIN
Slot0.1
429
OPEN = Not active
CLOSED = Active
P3.15.17.5 Pump 5 interlock Varies Varies
DigIN
Slot0.1
430
OPEN = Not active
CLOSED = Active
P3.15.17.6 Pump 6 interlock Varies Varies
DigIN
Slot0.1
486
OPEN = Not active
CLOSED = Active
P3.15.17.7 Pump 7 interlock Varies Varies
DigIN
Slot0.1
487
OPEN = Not active
CLOSED = Active
P3.15.17.8 Pump 8 interlock Varies Varies
DigIN
Slot0.1
488
OPEN = Not active
CLOSED = Active
Table 91: Overpressure supervision parameters
Index Parameter Min Max Unit Default ID Description
P3.15.18.1
Enable Overpressure
Supervision
0 1 0 1698
0 = Disabled
1 = Enabled
P3.15.18.2
Supervision Alarm
Level
Varies Varies Varies 0.00 1699
VACON · 178 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
