Vacon 100 flow Applications Manual

Table 59: Motor underload protection settings
Index Parameter Min Max Unit Default ID Description
P3.9.4.1 Underload Fault 0 3 0 713
0 = No action
1 = Alarm
2 = Fault (Stop accord-
ing to stop mode)
3 = Fault (Stop by
coasting)
P3.9.4.2
Underload Protec-
tion: Field Weaken-
ing Area Load
10.0 150.0 % 50.0 714
P3.9.4.3
Underload Protec-
tion: Zero Frequency
Load
5.0 150.0 % 10.0 715
P3.9.4.4
Underload Protec-
tion: Time Limit
2.00 200.00 s 20.00 716
Table 60: Quick stop settings
Index Parameter Min Max Unit Default ID Description
P3.9.5.1 Quick Stop Mode 0 2 Varies 1276
0 = Coasting
1 = Quick stop deceler-
ation time
2 = Stop according to
Stop function (P3.2.5)
P3.9.5.2 Quick Stop Activation Varies Varies
DigIN
Slot0.2
1213
OPEN = Activated
P3.9.5.3
Quick Stop Decelera-
tion Time
0.1 300.0 s Varies 1256
P3.9.5.4
Response to Quick
Stop Fault
0 2 Varies 744
0 = No action
1 = Alarm
2 = Fault (Stop accord-
ing to Quick stop mode)
VACON · 154 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
