Vacon 100 flow Applications Manual

2 Go to the item Access code and push the arrow
button Right.
STOP
READY ALARM Keypad
Main Menu
Normal
User level
00000
Access code
P8.2ID:2362
3 To change the digits of the access code, use all the
arrow buttons.
STOP
READY ALARM I/O
ID:2362 P8.2
Access code
Min:0
Max:9
00000
4 Accept the change with the OK button.
VACON · 202 USER SETTINGS, FAVOURITES AND USER LEVEL MENUS
8
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
