Vacon 100 flow Applications Manual

Table 117: Fieldbus Status Word
Bit
Descriptions
Value = 0 (FALSE) Value = 1 (TRUE)
Bit 0 Not ready to operate Ready to operate
Bit 1 Not running Running
Bit 2 Running in the Forward direction Running in the Reverse direction
Bit 3 No fault Fault is active
Bit 4 No alarm Alarm is active
Bit 5 Requested speed not reached Running at requested speed
Bit 6 Actual speed of the drive not zero Actual speed of the drive is zero
Bit 7 Motor not magnetized (flux not ready) Motor magnetized (flux ready)
Bit 8 Reserved Reserved
Bit 9 Reserved Reserved
Bit 10 Reserved Reserved
Bit 11 Reserved Reserved
Bit 12 Reserved Reserved
Bit 13 Reserved Reserved
Bit 14 Reserved Reserved
Bit 15 Reserved Reserved
V2.12.12 FB SPEED ACTUAL (ID 865)
This monitoring value shows the actual speed of the drive as a percentage of minimum
frequency and maximum frequency.
The value 0% indicates the minimum frequency and the value 100% indicates the maximum
frequency. This monitoring value is continuously updated depending on the momentary min
and max frequencies and the output frequency.
V2.12.13 FB DATA OUT 1 (ID 866)
This monitoring value shows the raw value of process data in a 32-bit signed format.
V2.12.14 FB DATA OUT 2 (ID 867)
This monitoring value shows the raw value of process data in a 32-bit signed format.
VACON · 214 MONITORING VALUE DESCRIPTIONS
9
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
