Vacon 100 flow Applications Manual

Table 6: M1 Quick Setup
Index Parameter Min Max Unit Default ID Description
1.22
I/O Control Refer-
ence A Selection
1 20 6 117
The selection of the
frequency reference
source when the con-
trol place is I/O A.
0 = PC
1 = Preset Frequency 0
2= Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Reference
8 = Motor Potentiome-
ter
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
The application that
you set with parameter
1.2 gives the default
value.
1.23
Keypad Control Ref-
erence Selection
1 20 1 121
See P1.22.
1.24
Fieldbus Control
Reference Selection
1 20 2 122
See P1.22.
1.25 AI1 Signal Range 0 1 0 379
0= 0..10V / 0..20mA
1= 2..10V / 4..20mA
1.26 AI2 Signal Range 0 1 1 390
0= 0..10V / 0..20mA
1= 2..10V / 4..20mA
1.27 RO1 Function 0 74 2 11001 See P3.5.3.2.1
1.28 RO2 Function 0 74 3 11004 See P3.5.3.2.1
1.29 RO3 Function 0 74 1 11007 See P3.5.3.2.1
1.30 AO1 Function 0 31 2 10050 See P3.5.4.1.1
VACON · 28 QUICK STARTUP GUIDE
1
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
