Vacon 100 flow Applications Manual

Table 12: M1 Quick setup
Index Parameter Min Max Unit Default ID Description
1.22
I/O Control
Reference A
Selection
1 20 6 117
The selection of the
frequency reference
source when the
control place is I/O A.
0 = PC
1 = Preset Fre-
quency 0
2= Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Reference
8 = Motor Potenti-
ometer
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
The application that
you set with parame-
ter 1.2 gives the
default value.
1.23
Keypad Con-
trol Refer-
ence Selec-
tion
1 20 1 121
See P1.22.
1.24
Fieldbus
Control Ref-
erence
Selection
1 20 2 122
See P1.22.
1.25
AI1 Signal
Range
0 1 0 379
0= 0..10V / 0..20mA
1= 2..10V / 4..20mA
1.26
AI2 Signal
Range
0 1 1 390
0= 0..10V / 0..20mA
1= 2..10V / 4..20mA
1.27
RO1 Func-
tion
0 74 2 11001
See P3.5.3.2.1
QUICK STARTUP GUIDE VACON · 71
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
1

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
