Vacon 100 flow Applications Manual

Table 13: M1.35 Multi-pump (Multidrive)
Index Parameter Min Max Unit Default ID Description
1.35.1 PID Gain 0.00 100.00 % 100.00 118
If the value of the
parameter is set to
100%, a change of
10% in the error
value causes the
controller output to
change by 10%.
1.35.2
PID Integration
Time
0.00 600.00 s 1.00 119
If this parameter is
set to, 1,00 s, a
change of 10% in
the error value
causes the control-
ler output to
change by
10.00%/s.
1.35.3
PID Derivation
Time
0.00 100.00 s 0.00 1132
If this parameter is
set to 1,00 s, a
change of 10% in
the error value
during 1.00 s cau-
ses the controller
output to change by
10.00%.
1.35.4
Process Unit
Selection
1 44 1 1036
Select the unit of
the process. See
P3.13.1.4
1.35.5 Process Unit Min Varies Varies Varies 1033
The process unit
value that is the
same as 0% of the
PID feedback sig-
nal.
1.35.6
Process Unit
Max
Varies Varies Varies 1034
The process unit
value that is the
same as 100% of
the PID feedback
signal.
1.35.7
Feedback 1
Source Selection
0 30 2 334
See P3.13.3.3
1.35.8
Setpoint 1
Source Selection
0 32 1 332
See P3.13.2.6
1.35.9
Keypad Setpoint
1
Varies Varies Varies 0 167
QUICK STARTUP GUIDE VACON · 73
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
1

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
