Vacon 100 flow Applications Manual

Table 13: M1.35 Multi-pump (Multidrive)
Index Parameter Min Max Unit Default ID Description
1.35.21 Autochange Days 0 127 1786
Range: Monday to
Sunday
1.35.22
Autochange Time
of Day
Time 1787
Range: 00:00:00 to
23:59:59
1.35.23
Autochange:
Frequency Limit
0.00 P3.3.1.2 Hz 25:00 1031
These parameters
set the level below
which the capacity
must stay for the
autochange to
start.
1.35.24
Autochange:
Pump Limit
1 6 1030
1.35.25 Bandwidth 0 100 % 10 1097
When the feedback
value stays
between 4.5 and .
5.5 bar, the motor
stays connected.
Setpoint = 5 bar
Bandwidth = 10%
When the feedback
value stays
between 4.5 and
5.5 bar, the motor
stays connected.
1.35.26 Bandwidth Delay 0 3600 s 10 1098
When the feedback
is outside the
bandwidth, the
time after which
pumps are added
or removed.
1.35.27
Constant Pro-
duction Speed
0 100 % 100 1513
Gives the constant
speed at which the
pump locks, when
the pump goes to
the maximum fre-
quency. The next
pump starts the
regulation in the
multimaster mode.
1.35.28 Pump 1 Interlock
DigIN
Slot0.1
426
OPEN = Not active
CLOSED = Active
1.35.29
Flushing Refer-
ence
Maximum
reference
Maximum
reference
HZ 50.00 1239
Gives the frequency
reference when the
flush function is
activated.
