Vacon 100 flow Applications Manual

4
Set a value for parameters P3.17.4 Fire Mode Acti-
vation on OPEN / P3.17.5 Fire Mode Activation on
CLOSE
Make a selection of a digital input to activate
Fire mode. See also Chapter 10.6.1 Program-
ming of digital and analogue inputs.
5
Set a value for parameter P3.17.6 Fire Mode
Reverse
Make a selection of a digital input to activate
the reverse direction in Fire mode.
DigIn Slot0.1 = FORWARD
DigIn Slot0.2 = REVERSE
6
Set a value for P3.17.1 Fire Mode Password Set a password to enable the Fire mode func-
tion.
1234 = Enable test mode
1002 = Enable Fire mode
The Fire mode wizard is completed.
WIZARDS VACON · 89
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
2

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
