Name Description
FUNCTION
KEYS
Enables you to assign behaviour to specific keys for specific areas.
Select an area and assign one of the following options to that area:
l None
l Unset
l Partset A
l Partset B
l Fullset
l Toggle Unset/Fullset
l Toggle Unset/Partset A
l Toggle Unset/Partset B
l All Okay
l Setting Authorisation
VISUAL
INDICATIONS
(Flexible Mode
only)
Enables you to assign specific behaviour to each LED on the indicator module. Each of the
LEDs has the following options:
l FUNCTION — the following options are available:
– KEYSWITCH — select a keyswitch and the position of the key.
– DISABLED — select to disable the LED.
– SYSTEM — select the alarm type which triggers the LED.
– AREA — select the area which triggers the LED.
– ZONE — select the zone which triggers the LED
– DOOR — select the door and the door option which triggers the LED.
l ON – COLOR — specify the activation colour
l ON – FLASH — specify the behaviour of the LED in active state. Available options are:
– Permanent — always on.
– Flash Fast/Medium/Slow — varying speed of the flashing.
l OFF – COLOR — specify the deactivation colour.
l OFF – FLASH — specify the behaviour of the LED in the inactive state. Available options
are:
– Permanent — always on.
– Flash Fast/Medium/Slow — varying speed of the flashing.
LED ALWAYS Enable if LED indicators remain active when keys are deactivated.
AUDIBLE IND.
(Flexible Mode
only)
Select the audible indicators for alarms, entry/exit, and keypresses,
DEACTIVATION
(Flexible Mode
only)
Choose one, or more, of the following deactivation options:
l Calendar – select a calendar from the available options.
l Keyswitch – select a keyswitch from the available options.
l Keypad - select a keypad from the available options.
l Card Reader – enable or disable deactivation using a keypad.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the keypad
© Vanderbilt 2018 130 A6V10276959-d
11.2018
