Tamper contact l SPC5320/5330: Front spring tamper, 2 auxiliary tamper contact inputs
l SPC5350: Front/back tamper switch
Power supply Type A (per EN50131-1)
Mains voltage 230V AC, + 10%/-15%, 50Hz
Mains fuse l SPC5320/5330: 250mA T (replaceable part on mains terminal block)
l SPC5350: 800mA T (replaceable part on mains terminal block)
Power consumption l SPC5320/5330: Max. 200mA at 230V AC
l SPC5350: Max. 500mA at 230V AC
Operating current l SPC5320/5330: Controller: Max. 200mA at 12V DC
l SPC5350: Max. 210mA at 12V DC
Quiescent current SPC53xx Controller: Max. 170mA at 12V DC (195mA with PSTN, 300mA
with GSM, 325mA with PSTN and GSM)
Output voltage 13–14V DC in normal conditions (mains powered and fully charged battery),
min. 10.5V DC when powered by secondary device (before system shut
down to battery deep discharge protection)
Low voltage trigger 11V DC
Overvoltage protection l SPC5320/5330: 15.7V DC
l SPC5350: 15V DC nominal
Peak to Peak ripple Max. 5% of output voltage
Auxiliary power (nominal) l SPC5320/5330: Max. 750mA at 12V DC
l SPC5350: Max. 2200mA at 12V DC (8 separately fused outputs, 300mA
per output)
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Technical Data
© Vanderbilt 2018 35 A6V10276959-d
11.2018
