17. Enter any values in the phone number, User name and Password fields and enter a name in
the Connection Name field.
18. Click Connect.
Windows 7 creates the connection.
19. Skip the Testing Internet Connection process.
20. Click Close.
21. In the Network and Sharing Center, click Change adapter settings.
22. Double-click the new modem.
The Connect Connection Name page opens, where Connection Name is the name you defined
for the modem.
23. Click Properties.
24. Ensure the Connect using: field contains the correct information, Communications cable
between two computers (COM3), for example.
25. Open your browser and enter the IP address of the Controller using https as the connection
protocol.
26. Click Continue Anyway if the browser displays a certificate error page.
27. Log on to the panel.
17.4 Logging into the browser
To log into the browser:
1. When an Ethernet or USB link is established and the IP address of the controller determined,
open the PC browser.
2. Enter the IP address in the address bar of the browser using the hyper text transfer protocol
secure. (For example, https://192.168.1.100.) See the table in Default settings for WEB server
address on the next page.
A page with a security message is displayed.
3. Click Continue to this website.
The login page is displayed.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 176 A6V10276959-d
11.2018
