Power consumption l SPC6330: Max. 200mA at 230V AC
l SPC6350: Max. 500mA at 230V AC
Operating current l SPC6330: Max. 200mA at 12V DC
l SPC6350: Max. 210mA at 12V DC
Quiescent current SPC63xx Controller: Max. 170mA at 12V DC (195mA with PSTN, 300mA
with GSM, 325mA with PSTN and GSM)
Output voltage l SPC6330: 13–14V DC in normal conditions (mains powered and fully
charged battery), min. 10.5V DC when powered by secondary device
(before system shut down to battery deep discharge protection)
l SPC6350: 13–14V DC in normal conditions (mains powered and fully
charged battery), min. 10.5V DC when powered by secondary device
(before system shut down to battery deep discharge protection)
Low voltage trigger 11V DC
Overvoltage protection l SPC6330: 15.7V DC
l SPC6350: 15V DC nominal
Peak to Peak ripple Max. 5% of output voltage
Auxiliary power (nominal) l SPC6330: Max. 750mA at 12V DC
l SPC6350: Max. 2200mA at 12V DC (8 separately fused outputs, 300mA
per output)
Battery type
(Battery not supplied)
SPC6330:
l YUASA NP17-12FR (12V/17Ah) - NF
l YUASA Yucel Y17-12IFR (12V/17Ah)
l YUASA Yucel Y24-12FR (12V/24Ah)
l PowerSonic PS12170 (12V/7Ah)
l PowerSonic PS12260 (12V/26Ah)
SPC6350:
l YUASA NP17-12FR(12V/17Ah) - NF
l FIAMM FGV22703 (12V/27Ah) - NF
l YUASA NPL24-12IFR (12V/24Ah)
l Alarmcom AB1227-0 (12V/27Ah)
l PowerSonic PS12260 (12V/26Ah)
Battery charger SPC63xx: Max. 24h to 80% of battery capacity
Battery protection l SPC6330: Current limited to 1A (fuse protected), deep discharge
protection at 10.5V DC +/- 3%
l SPC6350: Current limited to 2A (protected by PTC resettable fuse), deep
discharge protection at 10.5V DC, low voltage indicator at 11V DC
Software update Local and remote upgrade for controller, peripherals and GSM/PTSN modems.
Calibration No calibration checks required (calibrated at manufacturing)
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Technical Data
© Vanderbilt 2018 39 A6V10276959-d
11.2018
