Vanderbilt SPC42 Series User Manual

17.10.1.4 X10 Config - Settings
The X10 settings page allows you to configure the operation of X10 on the panel.
1. Select Configuration > Outputs > X-10.
The following page will be displayed:
2. Activate the checkbox Enable to enable X10 operation on the panel.
3. Activate the checkbox Log to enable logging of all X10 events on the panel.
4. Click Save.
5. Click an alphabetic tab (A-P) to program X10 device triggers.
A list of programmable device triggers (1–16) will be presented for that alphabetic character.
Unit
number
This is the number (1–16) that is assigned to the device.
Active This field indicates if the device is active or not.
Description This field displays a description that is used to help identify the device – for
example, downstairs light (16 characters max).
Quick key This field indicates if the X10 device activation can be toggled by entering a code
from the keypad.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 237 A6V10276959-d
11.2018
