Relay Outputs l SPC6320/6330 — 1 strobe (30V DC/1A resistive switching current)
l SPC6350 — 4 (single-pole changeover, 30V DC/ maximum 1A resistive
switching current)
Electronic Outputs l SP6320/6330 — 5 outputs:
– 2 internal/external bells
– 3 programmable. Maximum 400mA resistive switching current per
output, supplied by auxiliary output.
l SPC6350 — 8 outputs. Maximum 400mA resistive switching current per
output
– 5 standard power outputs
– 3 supervised outputs
Firmware V3.x
Door capacity Max. 64 entry doors or 32 entry/exit doors
Number of card reader Max. 64
Radio module Optional (SPCW110)
Verification 32 verification zones with max. 4 IP-cameras and 32 audio devices.
Video Up to 16 pre/16 post event images (by JPEG resolution 320 x 240, max. 1
frame/sec.)
Audio Up to 60sec. pre/60sec. post audio recording
Field bus 1) X-BUS on RS-485 (307kb/s)
Number of field devices 2) Max. 128 (32 keypads, 32 door-expanders, 64 input/output expanders)
Connectable field devices l Keypads: SPCK42x, SPCK62x
l Door expanders: SPCA210, SPCP43x
l Expanders with I/O: SPCE65x, SPCE45x, SPCP33x, SPCP35x,
SPCE110, SPCE120, SPCV32x
Interfaces l 2 X-BUS (2 spurs or 1 loop)
l 2 RS232
l 1 USB (PC connection)
l SPC63xx: Additionally 1 Ethernet (RJ45)
Tamper contact l SPC6330: Front spring tamper, 2 auxiliary tamper contact inputs
l SPC6350: Front/back tamper switch
Power supply Type A (per EN50131-1)
Mains voltage 230V AC, +10%/-15%, 50Hz
Mains fuse l SPC6330: 250mA T (replaceable part on mains terminal block)
l SPC6350: 800mA T (replaceable part on mains terminal block)
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Technical Data
© Vanderbilt 2018 38 A6V10276959-d
11.2018
