site. The tool can also be used in conjunction with the SPC cloud service SPC Connect to remotely
connect to customer sites and support them.
1. Select Communications > PC Tools > SPC Connect PRO.
2. Configure the fields as described in the table below then click Save.
SPC
Connect
PRO
Tick this box to enable SPC Connect PRO to connect to the panel.
Ethernet Tick this box to allow SPC Connect PRO to connect over Ethernet.
TCP
Port
Enter the TCP port on which the panel listens to incoming connections from SPC
Connect PRO.
USB Tick this box to allow SPC Connect PRO to connect over USB.
Serial 1
(X10)
Tick this box to allow SPC Connect PRO to connect over Serial 1 (X10).
Modem
1
Tick this box to allow SPC Connect PRO to connect over Modem 1.
17.11.4.2 SPC Manager
The SPC manager mode setting determines the number of digits for user PINs and therefore the
number of available PINs on a global system controlled by SPC Manager.
Mode41: 4-digit PIN enables 1,000 global users
Mode51: 5-digit PIN enables 10,000 global users
Mode61: 6-digit PIN enables 100,000 global users
Mode71: 7-digit PIN enables 1000,000 global users
Mode81: 8-digit PIN enables 10,000,000 global users
When you set an SPC Manager mode, additional zeros are added to the front of existing 4 or 5 digits
user PINs which modify the PIN for global use. For example, if Mode71: 7-PIN Digit is selected, 3
zeros are added to existing 4 digit PINs – 2222 will become 0002222.
To set the SPC Manager Mode:
1. Select Communications > PC Tools > SPC Manager.
2. Select the SPC Manager global user mode from the drop down list.
3. Click the Save button.
The mode cannot be saved if a conflict exists between a local existing user PIN and another user
PIN on the global system. An ‘Invalid PIN’ error is displayed.
4. Click the appropriate button to delete the PIN and save the new mode or change the PIN to the
randomly generated new PIN displayed and then save the new mode.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 336 A6V10276959-d
11.2018
