Setting Description
Direct Set Enable if Fullset/Partset function keys should be indicated in the LCD display.
Audible indications
Alarms Select speaker volume for alarm indications or disable sound.
Entry/Exit Range is 0–7 (max volume).
Chime Select speaker volume for entry and exit indications or disable sound.
Keypress Range is 0–7 (max volume).
Voice
Annunciation
Select speaker volume for chime or disable sound.
Partset
Buzzer
Range is 0–7 (max volume).
Deactivation
Calendar Select if the keypad should be limited by calendar.
Mapping
gate
Select if keypad should be limited by a mapping gate.
Keyswitch Select if keypad should be limited by a keyswitch.
PACE Entry Tick this box to disable the keys on the keypad during the entry time when a PACE is configured on
the keypad.
Areas
Location Select the secured area where the keypad is located.
Areas Select which areas can be controlled through keypad.
Options
Delay Fullset Select to configure a delayed set across all keypads. The location of the keypad is ignored and all
areas will perform a full exit time count down.
NOTICE: An area should be assigned to a keypad only if the keypad is inside the assigned area,
and if an entry/exit route is defined. If an area is assigned, when the particular area is set or unset
then entry and exit timers are used (if configured). Other features related to entry/exit routes also
become available. If no area is assigned, the area is set or unset immediately and other entry/exit
features are not available.
16.6.4.4 Edit Expanders
To edit expanders:
1. Scroll to EXPANDERS > EDIT.
2. Press SELECT.
3. Scroll to the device to be edited and press SELECT.
Parameters and details, if applicable, are displayed for editing.
4. Press BACK to exit the menu.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the keypad
© Vanderbilt 2018 128 A6V10276959-d
11.2018
