Vanderbilt SPC42 Series User Manual

Encryption
Password
Optional password used to provide increased security during initial ATP
commissioning. The password must be entered at the SPT or RCT
independently.
Reset
Encryption
Reset the Encryption Key and password to the default values.
ATP Profiles
Event Profile Select the Event Profile which defines how and which events are transmitted
on this ATS.
l Use ATS Setting
l Default Event Profile
l All events
Command
Profile
Select the Command Profile which defines the commands that are allowed on
this ATS.
l Use ATS Setting
l Default Command Profile
l Custom Command Profile
ATP Faults
ATP
Monitoring
Fault
Select to generate an ATP fault if the ATP monitoring fails or an event fails to
transmit on the ATP.
Event
Timeout
The amount of time that the ATP will keep trying to transmit the event until the
event fails on the ATP and is passed to the next ATP.
l 30 seconds
l 60 seconds
l 90 seconds
l 2 minutes
l 3 minutes
l 5 minutes
l 10 minutes
Minimum Message Lengths
Poll
Message
Minimum length of a poll message.
l 0 Bytes
l 64 Bytes
l 128 Bytes
l 256 Bytes
l 512 Bytes
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 313 A6V10276959-d
11.2018
