Name Description
KEY POSITIONS Enables you to assign behaviour to specific key positions for specific areas.
Select an area for the key position, and assign one of the following options to that area:
l None
l Unset
l Partset A
l Partset B
l Fullset
l Toggle Unset/Fullset
l Toggle Unset/Partset A
l Toggle Unset/Partset B
l All Okay
l Setting Authorisation
16.6.4.5 Edit Door Controllers
For further information about Door controllers, see Door Expander on page74.
1. Scroll to DOOR CONTROLLERS > EDIT.
2. Press SELECT.
3. Scroll to the device to be edited and press SELECT.
Parameters and details, if applicable, are displayed for editing as shown in the table below.
DESCRIPTION Name of the door controller
DOORS Configuration of Door I/O 1 and Door I/O 2.
READERS Configuration of Reader Profiles
To edit a DOOR I/O:
1. Scroll to DOORS.
2. Press SELECT.
3. Scroll to the DOOR I/O to be edited and press SELECT.
Parameters and details, if applicable, are displayed for editing as shown in the table below.
ZONES No access functionality is realized. The inputs and outputs can be
used normally.
DOOR 1 – DOOR
64
The selected door number is assigned to the DOOR I/O.
If the option “ZONES” is selected for a DOOR I/O the two inputs of this door I/O must be configured:
To edit the two zones of a DOOR I/O:
1. Scroll to the DOOR I/O to be edited and press SELECT
The option “Zones” is selected.
2. Press SELECT.
3. Select which Zone should be edited (DPS or DRS zone).
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the keypad
© Vanderbilt 2018 132 A6V10276959-d
11.2018
