Exceptions
Exceptions or exception days are used to configure automatic setting schedules for exceptional
circumstances outside of the normal weekly schedules defined in the calendars. Exceptions are
defined with a start and end date (day/month/year) and up to four on/off timing periods for different panel
operations including automatic setting/unsetting of areas or the switching on/off of triggers or outputs.
A maximum of 64 exceptions can be configured on the system.
Exceptions are generic entities that can be assigned to one or more calendars. When an exception is
assigned to a calendar, the exception settings override any calendar configuration for that start and end
date period with both dates inclusive.
Configuring Exception Days
1. Select Configuration > Calendars > Exception Days > Add.
The following page will be displayed.
2. Configure the fields as described in the table below.
Description Enter a name for the exception (16 characters max).
Start
Date/End
Date
Select the start and end date.
On
Time/Off
Time
Select the desired times for setting/unsetting or for triggers. Use time
guidelines for Automatic Setting/Unsetting of Areas (see Automatic
setting/unsetting of areas below), or for Automatic Setting/Unsetting of other
Panel Operations (see Automatic setting/unsetting of other panel operations
on the next page).
Calendars Select the desired calendar(s) for effect.
NOTICE: Global exception days created remotely using the SPC Manager tool cannot be deleted
or removed.
17.10.5.2 Automatic setting/unsetting of areas
A calendar can be configured for area auto-sets or auto-unsets.
For any day of the week, a configuration can have a maximum of 4 set times and 4 unset times.
Configured times use the 24 hour clock (hh:mm). If the hour is 24, then minutes must be 00, such as
midnight is 24:00. It is possible to define a set time without an unset and vice-versa. Configured times
trigger the area to either set or unset (provided all conditions are satisfied). Times entered are not
considered as a duration of time, rather they are a point in time that said action (set/unset) will occur. If
the controller is powered up or reset, the set/unset status is kept and subsequent set or unset times
occur according to configuration.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 286 A6V10276959-d
11.2018
