power diode (1N4001 for example, or similar) is also required, if not already present in the external device.
Number Description
1 Standard 12V Power output
2 Configurable, supervised, 12V DC logical switched output.
7.1.2 Batteries
This section covers:
l Installing Batteries on the facing page
l Testing Battery Voltage on page62
l Deep Discharge Protection on page62
l Battery Stand-By Times on page62
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Smart PSU
© Vanderbilt 2018 60 A6V10276959-d
11.2018
