Entering text
In Text Entry mode, both alphabetic characters (A–Z) and numeric digits (0–9) can be entered.
l To enter an alphabetic character, press the relevant key the required number of times.
l To enter a language specific special character (ä, ü, ö…) press button 1 to cycle through the
special characters.
l To enter a space + special characters (+, -./[]…) press button 0.
l To enter a digit, hold the relevant key down for 2 seconds and release.
l To move the position of the cursor one character to the left and right respectively, press the left
and right arrow keys.
l To exit from the feature without saving, press BACK.
l To save the programmed setting press ENTER or OK.
l To change the case of an alphabetic character, press the up/down arrow keys when the
character is highlighted by the cursor.
l To toggle between upper and lower case for all subsequent characters, press the hash (#) key.
l To delete character to the left of the cursor, press the star key(*).
Selecting a programming option
In navigation mode, the Engineer/User selects one of a number of pre-defined programming options
from a list.
l To scroll through the list of options available for selection, press the up and down arrow keys.
l To exit from the feature without saving, press BACK.
l To save the selected option, press SAVE or OK.
12.2 SPCK620/623
This section covers:
12.2.1 About the Comfort keypad 99
12.2.2 LED description 103
12.2.3 Viewing mode description 103
12.2.4 Function keys in idle state 104
12.2.1 About the Comfort keypad
The Comfort keypad is a wall-mounted interface that allows:
l Engineers to program the system through the Engineer Programming menus (password
protected) and to set/unset the system; a user can control the system on a day-to-day basis.
l Users to enter User Programming menus (password protected), and to perform operational
procedures (set/unset) on the system. (See the SPC620/623 User Manual for more details of
user programming)
The SPCK620 is equipped with soft keys and large graphical LCD for easy operation. The functionality
can be enhanced with key switch expander SPCE110 or indication expander SPCE120.
The SPCK623 is equipped with a proximity card reader (125 kHz EM 4102) for easy user access, soft
keys, large graphical LCD and voice annunciation support. The functionality can be enhanced with key
switch expander SPCE110 or indication expander SPCE120.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Keypad user interface
© Vanderbilt 2018 99 A6V10276959-d
11.2018
