Page #182 background imageLoading...
Page #182 background image
Name Description
Communication The physical status (OK, Fault) and the programmed status (OK, Isolated, Inhibited) of the X-
BUS cable connection to the expander.
Housing
Tamper
The physical and programmed status of the expander housing tamper.
Fuse Fault The physical and programmed status of the expander fuse.
Controller
Mains Fault
The physical and programmed status of the mains supply to the controller.
Battery Fault The physical and programmed status of the battery.
PSU Fault The physical and programmed status of the PSU.
OP Tamper The physical and programmed status of the tamper outputs on the PSU.
Low Voltage Indication of battery low voltage status.
Performable actions
Name Description
Restore
Alerts
Click the button to restore all alerts on the panel.
Inhibit Click this button to inhibit a fault condition. The inhibit operation will disable that fault or zone for one
arming period only.
Inhibit operation is not available in Security Grade EN 50131 Grade 3.
Isolate Click this button to isolate that zone. Isolating a zone will de-activate that zone until such time as the
zone is explicitly de-isolated again. It is recommended that you exercise caution when isolating
zones as those zones will not be active every time the system is SET.
See also
PSU status below
17.6.2.2 PSU status
The PSU Status page displays details of the current status of the PSU and its outputs in addition to the
status of any connected batteries.
The following PSU types are supported:
l SPCP332/333 Smart PSU
l SPCP355.300 Smart PSU
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 182 A6V10276959-d
11.2018
