Hardware Requirements
l The minimum battery capacity for SPC42xx/43xx/52xx/53xx/63xx is 10Ah/12V. If a 10Ah battery is
used, then the battery is biased to the left of the housing and the bottom flap is bent to meet the
battery.
l Fit jumper (J12) on the battery selector for 17/10Ah battery use and remove for 7Ah battery.
l The amount of current from Aux output using a 10Ah battery for SPC42xx/SPC52xx is:
COMMS
NONE (mA) PSTN (mA) GSM (mA) PSTN+GSM (mA)
Standby time
12 h 568 543 438 413
24h 214 189 84 59
30 h 143 118 13 N/A
60h 2 N/A N/A N/A
l The amount of current from Aux output using a 10Ah battery for SPC43xx/SPC53xx/ SPC63xx is:
COMMS
NONE (mA) PSTN (mA) GSM (mA) PSTN+GSM (mA)
Standby time
12 h 538 513 408 383
24 h 184 159 54 29
30 h 113 88 N/A N/A
60 h N/A N/A N/A N/A
3.5 PD 6662:2010 Conformance Guidelines
This document contains all the criteria for the installation, and commissioning and maintenance of the SPC
System to enable it to conform to the PD 6662:2010 Standard.
3.5.1 Product scope
The scope of this document is aimed at the following components of the SPC system:
SPC4320.320-L1 Grade2 Controller
SPC5320.320-L1 Grade2 Controller
SPC5330.320-L1 Grade3 Controller
SPC5350.320-L1 Grade3 Controller
SPC6330.320-L1 Grade3 Controller
SPC6350.320-L1 Grade3 Controller
SPCK420/421.100 LCD Keypad
SPCE452.100Expander, 8Relay Outputs
SPCE652.100Expander, 8Inputs/2Outputs
SPCP332.300 Smart PSU with I/O Expander
SPCP355.300Smart PSU with 8Inputs/2Outputs Expander
SPCP333.300 Smart PSU with I/O Expander
SPCN110.000 PSTN Module
SPCN320.000 GSM Module
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Directives and standards
© Vanderbilt 2018 23 A6V10276959-d
11.2018
