Audio Up to 60sec. pre/60sec. post audio recording
Field bus 1) X-BUS on RS-485 (307kb/s)
Number of field devices 2) Max. 11 (4 keypads, 2 door-expanders, 5 input/output expanders)
Connectable field devices l Keypads: SPCK42x, SPCK62x
l Door expanders: SPCA210, SPCP43x
l Expanders with I/O: SPCE65x, SPCE45x, SPCP33x, SPCE110,
SPCE120, SPCV32x
Interfaces l 1 X-BUS (1 spur)
l 1 RS232
l USB (PC connection)
l SPC43xx: Additionally 1 Ethernet (RJ45)
Tamper contact Front spring tamper, 2 auxiliary tamper contact inputs
Power supply Type A (per EN50131-1)
Mains voltage 230V AC, + 10%/ -15%, 50Hz
Mains fuse 250mA T (replaceable part on mains terminal block)
Power consumption SPC42xx: Max. 160mA at 230V AC
SPC43xx: Max. 200mA at 230V AC
Operating current SPC42xx Controller: Max. 160mA at 12V DC
SPC43xx Controller: Max. 200mA at 12V DC
Quiescent current SPC42xx Controller:
Max. 140mA at 12V DC (165mA with PSTN, 270mA with GSM, 295mA with
PSTN and GSM)
SPC43xx Controller:
Max. 170mA at 12V DC (195mA with PSTN, 300mA with GSM, 325mA with
PSTN and GSM)
Output voltage 13–14V DC in normal conditions (mains powered and fully charged battery),
min. 10.5V DC when powered by secondary device (before system shut down
to battery deep discharge protection)
Low voltage trigger 7.5V DC
Overvoltage protection 15.7V DC
Peak to Peak ripple Max. 5% of output voltage
Auxiliary power (nominal) Max. 750mA at 12V DC
Battery type
(Battery not supplied)
SPC422x/4320:
l YUASA NP7-12FR (12V/7Ah) - NF
l PowerSonic PS1270 (12V/7Ah)
l YUASA Yucel Y7-12FR (12V/7Ah)
Battery charger SPC422x/4320: Max. 72h to 80% of battery capacity
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Technical Data
© Vanderbilt 2018 32 A6V10276959-d
11.2018
