Description Enter a text describing the input (max. 16 characters). This text will also appear
on the browser and keypad.
Type The type of zone (see Zone types on page379).
Area Only if (multiple) Areas is activated in menu Panel Settings > System Settings
> Options. Select the areas to which this zone has been assigned.
Attributes An icon in this field indicates that attributes have been programmed for this zone
(see Input zones: attributes below).
Input zones: attributes
Each zone on the SPC can be assigned an attribute that determines the properties of that zone.
To assign an attribute to a zone:
1. Select Configuration > Hardware > Controller > Attributes.
The following page will be displayed:
2. Check the box beside the preferred attribute.
The attributes presented on this page will depend on the type of zone selected. For a list of
assignable attributes, see Applicable attributes to zone types on page387.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 230 A6V10276959-d
11.2018
