Door inputs
Each door has 2 inputs with predefined functionality. These two inputs, the door position sensor and the
door release switch can be configured.
Name Description
Zone The door position sensor input can be used for the intrusion part as well. If the door position sensor
input is used also for the intrusion part, the zone number it is assigned to has to be selected. If the
door position sensor is used only for the access part, the option “UNASSIGNED” has to be selected.
If the door position sensor is assigned to an intrusion zone, it can be configured like a normal zone
but only with limited functionality (for example, not all zone types are selectable).
If an area or the system is set with the card reader, the door position sensor input has to be assigned
to a zone number and to the area or the system which have to be set.
Description
(Web only)
Description of the zone the door position sensor is assigned to.
Zone Type
(Web only)
Zone type of the zone the door position sensor is assigned to (not all zones types are available).
Zone
attributes
(Web only)
The attributes for the zone the door position sensor is assigned to can be modified.
Area
(Web only)
The area the zone and the card reader are assigned to. (If the card reader is used for setting and
unsetting, this area will be set/unset).
Door
Position
(Web)
DPS End
Of Line
(keypads)
The resistor used with the door position sensor. Choose the used resistor value/combination.
DPS
Normal
Open
Select if the door release switch is to be a normally open or normally closed input.
Door
Release
(Web)
DRS END
OF LINE
(Keypads)
The resistor used with the door release switch. Choose the used resistor value/combination.
DRS
Normal
Open
Select if the door release switch is a normally open input or not.
No DRS
(Web only)
Select to ignore DRS.
If a DC2 is used on the door, this option MUST be selected. If not selected, the door will open.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the keypad
© Vanderbilt 2018 149 A6V10276959-d
11.2018
