Max. number of hardwired
zones
128
Max. number of wireless zones 120 (take away wired zones)
Max. number of Intrunet
wireless detectors per wireless
receiver (recommended)
20
EOL resistor Dual 4k7 (default), other resistor combinations configurable
Relay Outputs l SPC5320/5330 — 1 strobe (30V DC/1A resistive switching current)
l SPC5350 — 4 (single-pole changeover, 30V DC/ maximum 1A resistive
switching current)
Electronic Outputs l SPC5320/5330 — 5 outputs:
– 2 internal/external bells
– 3 programmable. Maximum 400mA resistive switching current per
output, supplied by auxiliary output.
l SPC5350 — 8 outputs. Maximum 400mA resistive switching current per
output
– 5 standard power outputs
– 3 supervised outputs
Firmware V3.x
Door capacity Max. 16 entry doors or 8 entry/exit doors
Number of card reader Max. 16
Radio module Optional (SPCW110)
Verification 16 verification zones with max. 4 IP-cameras and 16 audio devices.
Video Up to 16 pre/16 post event images (by JPEG resolution 320 x 240, max. 1
frame/sec.)
Audio Up to 60sec. pre/60sec. post audio recording
Field bus 1) X-BUS on RS-485 (307kb/s)
Number of field devices 2) Max. 48 (16 keypads, 8 door-expanders, 16 input/output expanders)
Connectable field devices l Keypads: SPCK42x, SPCK62x
l Door expanders: SPCA210, SPCP43x
l Expanders with I/O: SPCE65x, SPCE45x, SPCP33x, SPCP35x,
SPCE110, SPCE120, SPCV32x
Interfaces l 2 X-BUS (2 spurs or 1 loop)
l 2 RS232
l 1 USB (PC connection)
l SPC53xx: Additionally 1 Ethernet (RJ45)
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Technical Data
© Vanderbilt 2018 34 A6V10276959-d
11.2018
