1. Select Configuration > Advanced > Triggers.
The following page will be displayed.
2. Configure the fields as described in the table below.
Trigger System generated number for new trigger.
Trigger will only become active if one of the 2 optional steps (calendar/time
limitation) is configured
Description Enter a text description for the trigger.
Calendar Select a calendar, if required. If selected, the trigger will only be in effect during
this calendar period. See Calendars on page284.
Time limit Select a time period between 00:00 and 24:00 during which the trigger will only be
in effect. The Start time is inclusive, the end time is exclusive.
Note: This parameter delays a trigger transition from ON to OFF only; from OFF
to ON is immediate.
Timer Enter the number of seconds that the trigger conditions must be true before the
trigger will activate.
Trigger
Operation
l All All trigger conditions must be active for the system to activate the
trigger.
l Any Any trigger condition that is active enables the system to activate the
trigger.
Performable actions
Add Add conditions for the trigger. Click this button to add one or more conditions for the selected trigger.
See Trigger conditions on the facing page.
Exceptions Configure setting schedules for exceptional circumstances outside of the normal weekly schedules.
Edit/View Edit or view the selected calendar.
Delete Delete the selected calendar.
The calendar cannot be deleted if it is currently assigned to an SPC configuration item, i.e. zone,
area, user profile, output, trigger, door or X-Bus component. A message is displayed indicating the
assigned item.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 289 A6V10276959-d
11.2018
