Vigor VS Series User Manual

10
1-4 Overview of VS series PLC models
Main Specification
Model Name
★
VS1-10M -D
★
VS1-14M -D
★
VS1-20M -D
★
VS1-24M -D
★
VS1-28M -D
★
VS1-32M -D
VS1-32MT-DI
★
VS2-24M -D
★
VS2-32M -D
VS2-32MT-DI
VSM-Mini
VSM-14MT-D
★
VS-32XY
VS-28XYR
★
VS-16XY
★
VS-8XY
VS-8 / 16X
★
VS-8 / 16Y
VS-32XYT-I
VS-16XYT-I
VS-16X-I
VS-16YT-I
VS-PSD
-
VS 4AD
-
VS 2DA
-
VS 3A
-
VS 6A
-
VS 4TC
-
VS 8TC
-
VS 2PT
-
VS 4PT
Item
VS1 Series
Main Unit
VS2 Series
Main Unit
VSM Series
Main Unit
Special
Function
Module
DIO
Expansion
Module
VS3 Series
Main Unit
VS1 Main Unit: 6 DI (DC 24V, X0~X5 10 kHz); 4 DO ★; 16K words project memory; 1 Expansion Card socket;
I/O by screw-clamp terminal
VS1 Main Unit: 8 DI (DC 24V, X0~X7 10 kHz); 6 DO ★; 16K words project memory; 1 Expansion Card socket;
I/O by screw-clamp terminal
VS1 Main Unit: 12 DI (DC 24V, X0~X7 10 kHz); 8 DO ★; 16K words project memory; 2 Expansion Card sockets;
I/O by screw-clamp terminal
VS1 Main Unit: 4 DI (DC 24V, X0~X7 10 kHz); 10 DO ★; 16K words project memory;
2 Expansion Card sockets; I/O by screw-clamp terminal
VS1 Main Unit: 16 DI (DC 24V, X0~X7 10 kHz); 12 DO ★; 16K words project memory;
3 Expansion Card sockets; DIO Expansion Module available; I/O by screw-clamp terminal
VS1 Main Unit: 20 DI (DC 24V, X0~X7 10 kHz); 12 DO ★; 16K words project memory;
3 Expansion Card sockets; DIO Expansion Module available; I/O by screw-clamp terminal
VS1 Main Unit: 16 DI (DC 24V, X0~X7 10 kHz); 16 DO (100mA NPN transistor, Y0~Y3 50 kHz);
16K words project memory; 3 Expansion Card sockets; DIO Expansion Module available; I/O by IDC connector.
VS2 Main Unit: 12 DI (DC 24V, X0~X7 50 kHz); 12 DO ★; 32K words project memory; 2 Expansion Card sockets;
DIO Expansion & 8 Special Modules available; I/O by screw-clamp terminal
VS2 Main Unit: 16 DI (DC 24V, X0~X7 50 kHz); 16 DO ★; 32K words project memory; 3 Expansion Card sockets;
DIO Expansion & 8 Special Modules available; I/O by screw-clamp terminal
VS2 Main Unit: 16 DI (DC 24V, X0~X7 50 kHz); 16 DO (100mA NPN transistor, Y0~Y3 50 kHz);
32K words project memory; 3 EC sockets; DIO Expansion & 8 Special Modules available; I/O by IDC connector
VSM Development Tool Unit: Inner connected DI/DO (Y0~Y7 to X0~X7); 32K words project memory;
Memory Card Socket; CP1 RS-485 Communication Port
VSM Main Unit: 8 DI (DC 24V, 4×200 kHz + 4×50 kHz); 6 DO (500mA NPN transistor, Y0~Y3 200 kHz);
32K words project memory; 1 Expansion Card socket; I/O by screw-clamp terminal
VSM-32MT-DI
VSM-28ML-D
VSM-24MT-D
VSM-32MT-D
VSM Main Unit: 12 DI (DC 24V, 4×200 kHz + 4×50 kHz); 12 DO (500mA NPN transistor, Y0~Y3 200 kHz);
32K words project memory; 2 Expansion Card sockets; DIO Expansion & 8 Special Modules available;
I/O by screw-clamp terminal
VSM Main Unit: 16 DI (DC 24V, 4×200 kHz + 4×50 kHz); 16 DO (500mA NPN transistor, Y0~Y3 200 kHz);
32K words project memory; 3 Expansion Card sockets; DIO Expansion & 8 Special Modules available;
I/O by screw-clamp terminal
VSM Main Unit: 4 Line Driver DI (for 2 hardware counters up to 1 MHz) + 12 DI (DC 24V, 4×50 kHz & 8 normal);
8 Line Driver DO (4 × 1 MHz & 4 normal) + 4 DO (500mA NPN transistor); 32K words project memory;
3 Expansion Card sockets; DIO Expansion & 8 Special Modules available; I/O by screw-clamp terminal
VSM Main Unit: 16 DI (DC 24V, 4×200 kHz + 4×50 kHz); 16 DO (100mA NPN transistor, Y0~Y3 200 kHz);
32K words project memory; 3 Expansion Card sockets; DIO Expansion & 8 Special Modules available;
I/O by IDC connector.
VS3 Main Unit: 16 DI (DC 24V, 4×200 kHz + 4×50 kHz); 16 DO ★(Y0~Y3 200 kHz at NPN transistor model);
64K words project memory; 3 Expansion Card sockets; DIO Expansion & 16 Special Modules available;
I/O by screw-clamp terminal
VS3 Main Unit: 16 DI (DC 24V, 4×200 kHz + 4×50 kHz); 16 DO (100mA NPN transistor, Y0~Y3 200 kHz);
64K words project memory; 3 EC sockets; DIO Expansion & 16 Special Modules available; I/O by IDC connector
DI Expansion Module: 8 / 16 DI (DC 24V); input by screw-clamp terminal
DO Expansion Module: 8 / 16 DO ★; output by screw-clamp terminal
DIO Expansion Module: 4 DI (DC 24V); 4 DO ★; I/O by screw-clamp terminal
DIO Expansion Module: 8 DI (DC 24V); 8 DO ★; I/O by screw-clamp terminal
DIO Expansion Module: 16 DI (DC 24V); 12 DO (2A Relay); I/O by screw-clamp terminal
DIO Expansion Module: 16 DI (DC 24V); 16 DO ★; I/O by screw-clamp terminal
DI Expansion Module: 16 DI (DC 24V); input by IDC connector
DO Expansion Module: 16 DO (100mA NPN transistor); output by IDC connector
DIO Expansion Module: 8 DI (DC 24V); 8 DO (100mA NPN transistor); I/O by IDC connector
DIO Expansion Module: 16 DI (DC 24V); 16 DO (100mA NPN transistor); I/O by IDC connector
Power Repeater Module: DC 24V power input to transfer to DC 5V 500mA + DC 12V 800mA,
those inner power outputs provide for the Modules behind
Analog Input Module: 4 channel (16-bit) inputs, each channel could input either –10~+10V, 4~20mA or
–20~+20mA; isolated
Analog Output Module: 2 channel (16-bit) outputs, each channel could output either –10~10V, 4~20mA or
–20~+20mA; isolated
Analog I/O Module: 2 channel (16-bit) inputs + 1 channel (16-bit) output, each channel could input/output either
–10~+10V, 4~20mA or –20~+20mA; isolated
Analog I/O Module: 4 channel (16-bit) inputs + 2 channel (16-bit) outputs, each channel could input/output either
–10~+10V, 4~20mA or –20~+20mA; isolated
Thermocouple Temperature Input Module: 4 channel thermocouple (K, J, R, S, T, E, B or N type) inputs,
0.1℃ / 0.1℉ resolution ; isolated
Thermocouple Temperature Input Module: 8 channel thermocouple (K, J, R, S, T, E, B or N type) inputs,
0.1℃ / 0.1℉ resolution ; isolated
PT-100 Temperature Input Module: 2 channel (3-wire PT-100) inputs, 0.1℃ / 0.1℉ resolution ; isolated
PT-100 Temperature Input Module: 4 channel (3-wire PT-100) inputs, 0.1℃ / 0.1℉ resolution ; isolated
★
VS3-32M -D
VS3-32MT-DI
