When the power is turned from OFF to ON, the default value is 1.
The available range is 1~32,767, otherwise it is equivalent to 1.
#2
To assign the scale of temperature measurement. 0: ℃ ; 1: ℉ ; other values: ℃ . When the power is turned from OFF to
ON, the default value is 0.
#13
#14
Converted temperature value of PT3, with unit as 0.1 ℃ or 0.1 ℉ .
Converted temperature value of PT4, with unit as 0.1 ℃ or 0.1 ℉ .
#11
#12
Converted temperature value of PT1, with unit as 0.1 ℃ or 0.1 ℉ .
Converted temperature value of PT2, with unit as 0.1 ℃ or 0.1 ℉ .
#30
#31
Identication code: VS-4PT = K208 (can use the FROM instruction to check whether the place is this module or not)
The version number of this module. (the content value XX indicates Ver. X.X)
#29
Status and error ag.
#3
#4
#5
To set the average times of PT3.
To set the average times of PT4.
#6
To set the average times of PT2.
To set the average times of PT1.
BFM No.
Component Description
b0
b1b2
b3b14～b4b15
PT1 is disconnected or converted value
exceeds the range
PT2 is disconnected or converted value
exceeds the range
PT3 is disconnected or converted value
exceeds the range
PT4 is disconnected or converted value
exceeds the range
BFM #29 Status and Error Flag: (0: normal; 1: error)
2-17-8 Buffer Memory BFM in the VS-4PT Module
Module's external DC 24V
supply is missing or has a
hardware error
