Vigor VS Series - VS-D232-EC Communication Expansion Card

367
1306-
0001
VS-D232-EC
VIGOR
SG
RX TX
CH2
SG
RX TX
CH1
7-2-6 VS-D232-EC Communication Expansion Card
The VS-D232-EC Communication Expansion Card offers two sets of non-isolated RS-232C port. By way of the
parameter setting and well planned program at the VS Series PLC Main Unit, each port can separately perform one of
various communication functions.
VIGOR LOGO
30mm
64mm
25mm 15mm
RS-232C RS-232C
D232
RX TX
CH1
RX TX
CH2
Product Exterior
Fix Clip (lower)
Fix Clip (upper)
CH1 Communication
Connecting Terminal
CH2 Communication
Connecting Terminal
Brief Model Name
Expansion Card
Connector
CH1 CH2
TX (transmitting) and RX (receiving)
Half-duplex
By the setting of installed project (115,200 bps. Max.)
DC5V 25mA (from PLC Main Unit)
By the installed project (via the "COM Port setting" page in the programming software)
Fixed 5mm Screw-Clamp Terminal Block
Product Specification
Item
Specification
Communication Interface
Isolation Method
Communication Indicator
Max. Communication
Communication Method
Baud Rate
Power Consumption
Wiring Method
Parameter Conguration
No isolation No isolation
TX (transmitting) and RX (receiving)
15 M 15 M
Half-duplex
Fixed 5mm Screw-Clamp Terminal Block
CH1 Communication
Status Indicator
CH2 Communication
Status Indicator
Serial Number
Complete
Model Name
Manufacturer
