365
1306-
0001
VS-D485-EC
VIGOR
7-2-4 VS-D485-EC Communication Expansion Card
The VS-D485-EC Communication Expansion Card offers two sets of non-isolated RS-485 port. By way of the
parameter setting and well planned program at the VS Series PLC Main Unit, each port can separately perform one of
various communication functions.
VIGOR LOGO
CH1 Communication
Connecting Terminal
30mm
64mm
25mm 15mm
D485
TRTR
SG
DD
RX TX
CH1
RX TX
CH2
CH1
TRTR
SG
DD
CH2
Fix Clip (lower)
Fix Clip (upper)
Product Exterior
Expansion Card
Connector
CH1 Communication
Status Indicator
CH2 Communication
Status Indicator
CH2 Communication
Connecting Terminal
RS-485 RS-485
CH1 CH2
TX (transmitting) and RX (receiving)
Half-duplex
By the setting of installed project (115,200 bps. Max.)
DC5V 100mA (from PLC Main Unit)
By the installed project (via the "COM Port setting" page in the programming software)
Fixed 5mm Screw-Clamp Terminal Block
120Ω, enabled when two TR terminals are short-connected
Product Specification
Item
Specification
Communication Interface
Isolation Method
Communication Indicator
Max. Communication Distance
Communication Method
Baud Rate
Power Consumption
Wiring Method
Terminal Resistor
Parameter Conguration
No isolation No isolation
TX (transmitting) and RX (receiving)
50 M 50 M
Half-duplex
Fixed 5mm Screw-Clamp Terminal Block
Terminal Resistor
Connecting Terminal
Brief Model Name
Terminal Resistor
Connecting Terminal
Serial Number
Complete
Model Name
Manufacturer
To Next Page
