Vigor VS Series - Page 280

274
D C O S P
S
D
1
2
M
3
○○○○
FNC
131
X Y M S
D.b R.b
KnX KnY
KnM KnS
T C
D,R
V,Z
UnG
K,H
E
" $"
S
D
DCOS D0 D10
X0
S
D
S
D
Operand
Devices
Calculate Cosine
This instruction performs the mathematical cosine operation on the designated BIN oating point radians of
angle, and the result is stored in the designated device.
When X0 = “ON”, the instruction is activated, it uses the BIN oating point radians at (D1, D0) to calculate the
cosine value, and the result will be stored at the specied destination devices (D11, D10).
For to convert the angle unit between the radians and degrees, please refer to the DEG and RAD instructions.
S : the source device for input the angle in radians
D : the calculated result
Radian = Degree × π / 180
This instruction is a 32-bit instruction. Therefore, be sure to input DCOS or DCOSP in the program.
S
D
The source operand must assign to a BIN oating point number for the calculation, and the calculated result
is by the BIN oating point format, too.
The format for storing a oating point number will occupy two Registers in the PLC system. Please refer to the
section 2-13 “Numerical System” for the reference of the oating point number.
