279
D R A D P
S
D
1
2
M
3
○○○
FNC
136
X Y M S
D.b R.b
KnX KnY
KnM KnS
T C
D,R
V,Z
UnG
K,H
E
" $"
S
D
DRAD D0 D10
X0
S
D
S
D
○
Operand
Devices
Convert Angle From Degrees to Radian
X0＝ON
1.04719860
Angle by degrees
Angle by radians
(D1, D0) BIN floating number (D11, D10) BIN floating number
This instruction is a 32-bit instruction. Therefore, be sure to input DRAD or DRADP in the program.
S
D
The source operand must assign to a BIN oating point number for the calculation, and the calculated result
is by the BIN oating point format, too.
The format for storing a oating point number will occupy two Registers in the PLC system. Please refer to the
section 2-13 “Numerical System” for the reference of the oating point number.
Radian = Degree × π / 180
S : the source device for input the angle in degrees
D : the calculated result in radians
This instruction performs the mathematical converting operation on the designated BIN oating point degrees
of angle, and the result of radians is stored in the designated device.
When X0 = “ON”, the instruction is activated, it uses the BIN oating point degrees at (D1, D0) to convert, and the
result of radians will be stored at the specied destination devices (D11, D10).
