– Unscrew securing bolt for sprockets completely and remove
sprockets with timing chains from oil pump.
– Unscrew oil pump securing bolts -arrows-.
– Lever oil pump out evenly at lugs -arrows-.
Installing:
Note
♦
Do not tilt oil pump when installing.
♦
Renew O-ring and securing bolt for the sprockets.
♦
Insert securing bolts for oil pump with locking fluid.
– Install oil pump, coat securing bolts -arrows- with locking
agent, then tighten bolts. Specified torque
⇒ Item 8 (page 117) .
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
124 Rep. gr.17 - Lubrication
