28 – Ignition system
1 Ignition system
⇒ “1.1 General notes on ignition system”, page 269
⇒ “1.2 Assembly overview - ignition system”, page 269
⇒ “1.3 Safety precautions”, page 271
⇒ “1.4 Test data, spark plugs”, page 272
⇒ “1.5 Removing and installing ignition coils with output stage”,
page 272
⇒ “1.6 Removing and installing engine speed sender G28 ”, page
274
1.1 General notes on ignition system
♦ For trouble-free operation of electrical components, a voltage
of at least 11.5 V is necessary.
♦ Certain tests may lead to an event being detected by the con‐
trol unit and stored. Then after completing all checks and
repairs, read event memory and erase if necessary ⇒ vehicle
diagnostic tester “Guided functions”.
♦ If, after fault finding, repairs or component tests, the engine
starts, runs for a short period and then stops, then the fault
may be that the immobilizer is blocking the engine control unit.
In this case, the control unit must be adapted using ⇒ vehicle
diagnostic tester under “Guided functions”.
1.2 Assembly overview - ignition system
Note
The engine speed sender - G28- can be found on the cylinder
block ⇒ Item 26 (page 33) .
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
1. Ignition system 269
