1.4 Test data, spark plugs
Engine code CGRA, CMTA
Firing order 1-5-3-6-2-4
Spark plugs
5)
VW/Audi 101 905 622
Electrode gap 0.8 to 0.9 mm
Specified torque 18 Nm
Change interval ⇒ Maintenance ; Booklet 17.1 ; Service
tables
5) Current spark plugs ⇒ Electronic parts catalogue (ETKA)
1.5 Removing and installing ignition coils
with output stage
Special tools and workshop equipment required
♦ Puller - T10095 A-
♦ Assembly tool - T10118-
Removing:
– Unclip cover rail for ignition cable harness -arrows- and re‐
move forwards from retaining lugs -A-.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
272 Rep. gr.28 - Ignition system
