5 Senders and sensors
⇒ “5.1 Checking fuel pressure sender G247 ”, page 243
5.1 Checking fuel pressure sender - G247-
Special tools and workshop equipment required
♦ Assembly tool - T10118-
♦ Open ring spanner with 3/8" drive, width across flats 27 mm
(flared spanner)
♦ Pressure sensor tester - VAS 6394-
♦ Test instrument adapter/DSO (3-pin) - VAS 5570-
Procedure:
WARNING
♦ The fuel pressure sender is under pressure! Wear protec‐
tive goggles and protective clothing to avoid injury and
contact with the skin. Before loosening fuel pressure send‐
er, wrap a cloth around the connection. Then release
pressure by carefully loosening the connection.
